1756-OA8D

Get a Quote

Current response time:

16 Minutes 18 Seconds
  • Description: Diagnostic Output Module | ControlLogix
  • Product Type: AC diagnostic output module
  • Outputs: 8 diagnostic, electronic fusing (4 points/group)
  • Voltage category: 120V AC 50/60 Hz
  • Operating voltage range: 74...132V AC 47...63 Hz
  • Current draw @ 5.1V: 175 mA
  • Current draw @ 24V: 250 mA
  • Total backplane power: 6.89 W
  • Thermal dissipation: 18.0 BTU/hr
  • Off-state leakage current, max: 3 mA per point
  • On-state voltage drop, max: 2.5V peak @ 0.5 A 3V peak @ 1 A
  • Load current, min: 10 mA per point
  • Inhibit voltage, max: Zero crossing 25V peak
  • Isolation voltage: 125V (continuous)
  • Fusing: Electronically fused per point
  • Output delay time, Off to On: 9.3 ms @ 60 Hz | 11 ms @ 50 Hz
  • Output delay time, On to Off: 9.3 ms @ 60 Hz | 11 ms @ 50 Hz
