- Description: Output Module | ControlLogix
- Product Type: AC Digital Isolated Output Module
- Product Series: 1756 ControlLogix I/O Modules
- No. of Outputs: 16 Individually Isolated
- Voltage Category: 120/240V AC, 50/60 Hz
- Operating Voltage Range: 74...265V AC | 47...63 Hz
- Output Delay Time; Off to On: 9.3ms @ 60Hz | 11ms @ 50Hz
- Output Delay Time; On to Off: 9.3ms @ 60Hz | 11ms @ 50Hz
- Current Draw @ 24V: 2.5 mA
- Current Draw @ 5.1V: 300 mA
- Total Backplane Power: 1.59 W
- Thermal Dissipation: 18.76 BTU/hr
- Off-State Leakage Current, max.: 3 mA per point
- On-State Voltage Drop, max.: 1.5V peak @ 2 A | 6V peak @ load current < 50 mA
- Load Current, min.: 10 mA per point
- Pilot Duty: Yes
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 1756-OA16I . Santa Clara Systems carries 54,584 items from Allen Bradley.
