LS-7601

Keyence - Micrometer

Current response time:

13 Minutes 20 Seconds

Description: Micrometer
Weight: Approx 1010 g
Footnotes: *1 The rating of the NPN open-collector inside the terminal block is: 100 mA max. (40 V max.), with a residual voltage of 0.5 V max. The rating of the NPN open-collector inside the connector I/O is: 30 mA max. (30 V max.), with a residual voltage of 0.5 V max. The rating of non-voltage input is: ON voltage of 1 V max., OFF current of 0.6 mA max. *2 Either SUB mode or BCD mode can be selected. *3 AC power supply can be used when the LS-S11 (AC power supply stand) is connected.
Type: High-performance
No. of connectable measuring heads: 2 (All types)
Display - Measurement display: TFT 5.5-inch LCD display, Backlight: CCFL (Average life: 40,000 hours)
Display - Minimum display unit: 0.01 m to 100 m (7-level selectable)
Display - Display range: 99.99999 to9,999.9 mm 3.937" to 393.7" (linked to the minimum display unit, mm/ m selectable)
Display - Measurement position monitor: Monitor image (When the measuring head with the monitor function is connected.)
Display - Tolerance check output display: 5-level LCD indicator
Terminal block - Alarm output: NPN open-collector output (N.C.)*1
Terminal block - 5-level judgment output judgment ready output strobe output: NPN open-collector output for OUT1*1
Terminal block - Comparator ready output: NPN open-collector output for OUT1*1
Terminal block - Program selection input: Non-voltage input x 4 inputs*1
Terminal block - Strobe output: NPN open-collector output for OUT1*1
Terminal block - Statistical processing input: Non-voltage input for OUT1*1
Terminal block - Timing input reset input auto-zero input: Non-voltage input for OUT1*1
Terminal block - Analog output: 10 V x 2 outputs*1
Terminal block - Reset input: Non-voltage input for OUT1*1
Terminal block - Auto-zero input: Non-voltage input for OUT1*1

Connector I/O - SUB mode - Statistical processing output: NPN open-collector output x 2 outputs*2
Connector I/O - SUB mode - Function output: Selectable from focus, area check, and difference check, NPN open-collector output x 2 outputs*2
Connector I/O - SUB mode - 5-level judgment output judgment ready output strobe output: NPN open-collector output for OUT2*2
Connector I/O - SUB mode - Comparator ready output: NPN open-collector output for OUT2*2
Connector I/O - SUB mode - Strobe output: NPN open-collector output for OUT2*2
Connector I/O - BCD mode - BCD output: Measurement data output (Sign + 7 digits), OUT1/OUT2 selectable, NPN open-collector output*2
Connector I/O - BCD mode - BCD selection output: NPN open-collector output*2
Connector I/O - BCD mode - BCD selection input: Non-voltage input*2
Connector I/O - Statistical processing input: Non-voltage input for OUT2
Connector I/O - Timing input reset input auto-zero input: Non-voltage input for OUT2
Connector I/O - Reset input: Non-voltage input for OUT2
Connector I/O - Auto-zero input: Non-voltage input for OUT2
RS-232C interface: Measurement data output and control I/O, printer (Baud rate can be selected up to 115.200 bps)
Video output: Conforming to the NTSC system (RCA connector)
Major functions: Simultaneous measurement, area designation, calculation, averaging, calibration, 16-program memory, measurement, auto-zero, print-out, abnormal value elimination, transparent object measurement, measurement point display, group comparison, unacceptable va
Rating - Power voltage: 24 VDC 10%*3
Rating - Power consumption: 1.2 A max.*3
Environmental resistance - Enclosure rating: IP64 (Panel surface only)
Environmental resistance - Operating temperature range: 0 to +40? 32F to 104F
Environmental resistance - Operating ambient humidity: 35 to 85% RH (No condensation)
