- Description: Pressure/Vacum Sensor Model
- Weight: 30 g (not including cables) / 78 g (including 2-m cable)
- Type: 101.3 tp -101.3 lPa, PNP
- Pressure resistance: 500kPa
- Adaptive fluids: Air, non-corrosive gasses
- Pressure type: Gauge pressure
- Rating - Power supply voltage: 12 to 24 V DC +10% Ripple (P-P) 10% max.
- Rating - Current consumption - Normal - 12 V operation (NPN/PNP): 720 mW(60 mA)/900 mW (75 mA) max.
- Rating - Current consumption - Normal - 24 V operation (NPN/PNP): 960 mW(40 mA)/1320 mW(55 mA) max.
- Rating - Current consumption - Eco mode - 12 V operation (NPN/PNP): 480 mW(40 mA)/600 mW(50 mA) max.
- Rating - Current consumption - Eco mode - 24 V operation (NPN/PNP): 720 mW(30 mA)/960 mW(40mA) max.
- Display method: 3.5 digit two-color 7 segment LED (11 mm character height) Display cycle: 10 time/seconds
- Operating status indicators: Red LED x 2 (supports control output 1 / control output 2)
- Enviromental resistance - Ambient temperture: 0 to +50 *C (no freezing)
- Enviromental resistance - Relative humidity: 35 to 85% RH (no condensation)
- Enviromental resistance - Vibration: 10 to 55 Hz, compound amplitude 1.5 mm, 2 hours for each of X, Y, and Z axes.
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on AP-C30KP . Santa Clara Systems carries 2,107 items from Keyence.
We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
