Out of Stock

14102AS6515

Cutler-Hammer - Photoelectric Sensor

Current response time:

18 Minutes 16 Seconds

Description: Photoelectric Sensor
Input Voltage: 90-132 Vac/18-50 Vdc
Contact Configuration: 2 Wire AC/DC
Operating Mode: Non Polarized Retroreflective
Operating Temperature: -13 to 158F (-25 to 70C)
Switch Type: Photoelectric
Cord Length: 79.2 FT
Maximum Ac Current: 300 mA
Maximum Dc Current: 300 mA
Connection: 6.6 Ft. ( 2m ) Cable
Cable Type: PVC
Sensor Type: Retroreflective

Contact Rating: 300 mA at 90-132 Vac/18-50 Vdc
Environmental Rating: NEMA 1,3,4,4X,6,6P,12,13, IP68, IP69K
Protection: Auto reset short circuit
Diameter: .71 IN
Led Indicators: Red output status
Product Length/Depth: .47 IN
Product Height: 2.6 IN
Product Width: .71 IN
Product Weight: .2875 LB
Compliances: CE Marked
Certifications: cUL Recognized

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 14102AS6515 . Santa Clara Systems carries 16,181 items from Cutler-Hammer.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
