1756-IF16H

Allen Bradley - Analog Input | ControlLogix 16 Point Hart

Current response time:

13 Minutes 57 Seconds

* Santa Clara Systems is not a Rockwell Automation Authorized Distributor .

Description: Analog Input | ControlLogix 16 Point Hart
Resolution: 16...21 bits
Product Type: Current Analog Input Module with HART Protocol
Product Series: 1756 ControlLogix I/O Modules
Inputs: 16
Backplane Voltage: 225 mA @ 5.1V DC, 200 mA @ 24V DC
Input Current Range: 0...20 mA, 4...20 mA
Power dissipation: 5.30 W
Inrush current: 400 mA @ 5.1V DC | 450 mA @ 24V DC

Isolation voltage: 250V (continuous)
Open circuit detection time: 5 s, 420 mA range only
Input overvoltage protection: 28.8V DC
Calibration interval: 12 months typical
Module error over full temperature range with HART disabled: 0.3% of range (all filters)
Module scan time for all channels - analog, min: 14...428 ms (filter dependent)
Typical module HART dynamic variables update time for all channels: 1 s typical with no pass through or device information messaging active
Data format: IEEE 32-bit floating point
Input & Output conversion method: Sigma-Delta ADC (24-bit converter)

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on 1756-IF16H . Santa Clara Systems carries 54,520 items from Allen Bradley.
