ABB CAL4-11RT CAL4-11RT Auxiliary Contact Block Product Image

CAL4-11RT

ABB - CAL4-11RT Auxiliary Contact Block

Current response time:

By 5AM PT on Thursday

Emergency?

Description: CAL4-11RT Auxiliary Contact Block
Product ID: 1SBN010129R1011
Extended Product Type: 1SBN010129R1011
Product Net Weight: 0.040 kg
Product Net Width: 0 mm
Product Net Height: 0 mm
Product Net Depth: 0 mm
Product Main Type: Accessories for Block Contactors
Product Name: Auxiliary Contact Block
Rated Impulse Withstand Voltage (Uimp): 6 kV
Rated Insulation Voltage (Ui): acc. to IEC 60947-5-1 and VDE 0110 (Gr. C) 690 V
Terminal Type: Ring-Tongue Terminals
Rated Frequency (f): Auxiliary Circuit 50 / 60 Hz
Suitable For: AF09 AF12 AF16 AF26 AF30 AF38 AF40 AF52 AF65 AF80 AF96 NF
Tightening Torque: Main Circuit 1.2 N·m
Number of Auxiliary Contacts NO: 1
Number of Auxiliary Contacts NC: 1
Maximum Mechanical Switching Frequency: 3600 cycles per hour
EAN: 3471523130449
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85389099
Package Level 1 Units: 1 piece
Package Level 1 Width: 125 mm
Package Level 1 Height: 20 mm
Package Level 1 Length: 125 mm
Package Level 1 Gross Weight: 0.04 kg
Package Level 1 EAN: 3471523130449

Package Level 2 Units: 0 piece
Package Level 2 Width: 0 mm
Package Level 2 Height: 0 mm
Package Level 2 Length: 0 mm
Package Level 3 Units: 0 piece
Product Packing Type: Bag
RoHS Status: Planned to follow EU Directive 2002/95/EC August 18, 2005 and amendment after 2008 Q4
Conventional Free-air Thermal Current (Ith): acc. to IEC 60947-5-1, q = 40 C 16 A
Fire and Smoke Standards: ASTM E 1354 ASTM E 162 ASTM E 662 BSS 7239 DIN 5510-2 EN 45545 (Hazard levels HL2, HL3) NF F 16-101 / NF F 16-102
IIT Publishing Status: Level 0 - Information enabled
Maximum Electrical Switching Frequency: AC-15 1200 cycles per hour DC-13 900 cycles per hour
Rated Operational Current AC-15 (Ie): (220 / 240 V) 4 A (24 / 127 V) 6 A (400 / 440 V) 3 A (500 V) 2 A (690 V) 2 A
Rated Operational Current DC-13 (Ie): (110 V) 0.55 A / 60 W (125 V) 0.55 A / 69 W (220 V) 0.27 A / 60 W (24 V) 6 A / 144 W (250 V) 0.27 A / 68 W (400 V) 0.15 A / 60 W (48 V) 2.8 A / 134 W (500 V) 0.13 A / 65 W (600 V) 0.1 A / 60 W (72 V) 1 A / 72 W
Rated Operational Voltage: Auxiliary Circuit 24 ... 690 V
Rated Short-time Withstand Current (Icw): for 0.1 s 140 A for 1 s 100 A
RoHS Date: 20121001
CB Certificate: CB_SE_70921
CCC Certificate: CCC_2011010304496319
Data Sheet, Technical Information: 1SBC100178C0201
Declaration of Conformity - CE: 1SBD250007U1000
EAC Certificate: EAC_RU C-FR ME77 B01048
RoHS Information: 1SBD251018E1000
ETIM 4: EC002498 - Accessories for low-voltage switch technology
ETIM 5: EC002498 - Accessories for low-voltage switch technology
ETIM 6: EC002498 - Accessories for low-voltage switch technology
Object Classification Code: K
UNSPSC: 39121500

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on CAL4-11RT . Santa Clara Systems carries 36,941 items from ABB.

Delivered Open And Protected Against Accidental Direct Contact And Bear The Corresponding Function Marking.

Cal4-11rt Auxiliary Contact Blocks Are Used For The Operation Of Auxiliary Circuits And Control Circuits For Standard Environments. Cal4-11rt Are 2-Pole Block
With Instantaneous N.o. + N.c. Contacts
For Clipping Onto The Right- And/or Left-Hand Side Of The Contactors. The Auxiliary Contact Blocks Are Equipped With Non-Detachable Screw With Conic Washer For A Fast And Secure Tightening Of Cables With Ring Tongue Ferrules
