P1KH013

Wenglor - Reflex Sensor

Product Summary:

Range: 150 mm
Setting Range: 30 ... 150 mm
Switching Hysteresis: < 10 %
Light Source: Red Light
Service Life (T = +25 C): 100,000 h

Current response time:

By 5AM PT on Monday

Emergency?

Description: Reflex Sensor
Range: 150 mm
Setting Range: 30 ... 150 mm
Switching Hysteresis: < 10 %
Light Source: Red Light
Service Life (T = +25 C): 100,000 h
Max. Ambient Light: 10,000 Lux
Light Spot Diameter: See Table 1
Supply Voltage: 10 ... 30 V DC
Supply Voltage with IO-Link: 18 ... 30 V DC
Current Consumption (Ub = 24 V): < 20 mA
Switching Frequency: 1,000 Hz
Switching Frequency (interference-free mode): 500 Hz
Response Time: 0.5 ms

Response time (interference-free mode): 1 ms
Temperature Drift: < 5 %
Temperature Range: -40 ... 60 C
Switching Output Voltage Drop: < 2 V
Switching Output/Switching Current: 100 mA
Residual Current Switching Output: < 50 A
Short Circuit and Overload Protection: yes
Reverse Polarity Protection: yes
Lockable: yes
Interface: IO-Link V1.1
Protection Class: III
Setting Method: Potentiometer
Housing Material: Plastic

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on P1KH013 . Santa Clara Systems carries 3,781 items from Wenglor.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
