- Description: Ethernet TCP/IP communication module
- Product weight: 0.66 lb(US) (0.3 kg)
- Range of product: Altivar
- Electrical connection: 1 connector RJ45 Ethernet/IP, 1 connector RJ45 Modbus TCP
- Category: 18263 - LEXIUM 32 ACCESSORIES
- Returnability: Y
- Country of origin: CN
- Range compatibility: Lexium 32, Altivar Machine ATV320, Altivar 32
- Product or component type: Communication module
- Communication port protocol: Ethernet/IP, Modbus TCP
- Discount Schedule: PC51
- GTIN: 785901924975
- Transmission rate: 10/100 Mbps
- Nbr. of units in pkg.: 1
- Addressing: IP addressing manual, BOOTP or DHCP
- Package weight(Lbs): 0
- Exchange mode: Half duplex and full duplex
- Communication service: Up to 8 connections (includes connections of Modbus TCP/Ethernet IP) Ethernet IP/Modbus TCP, FDR Agent Ethernet IP/Modbus TCP, Read holding registers (03), 63 words max Modbus TCP, Read input registers (04), 63 words max Modbus TCP, Write single register (06) Modbus TCP, Write multiple registers (16), 63 words max Modbus TCP, Read/write multiple registers (23) Modbus TCP, Read device identification (43) Modbus TCP, Diagnostics (08) Modbus TCP, I/O scanner : read/write, 6 words maximum Modbus TCP, Communication monitoring Modbus TCP, SNMP agent Ethernet IP, Master/Slave hierarchy ODVA AC drive profile and CiA 402 profile Ethernet IP, Fixed communication monitoring adjusted by Ethernet IP scanner adaptor (Master) Ethernet IP
- Web server: Embedded HTTP server
- Web services: Ethernet/IP scanner setup, Ethernet statistics, Ethernet/IP setup, Security, Drive parameters, Drive monitor, Message statistics
- Display type: 1 LED MS (Module Status), 1 LED NS (Network Status), 1 LED Ethernet port activity, 1 LED Modbus TCP port activity
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on VW3A3616 . Santa Clara Systems carries 10,317 items from Telemecanique.
- Ethernet Tcp/ip Communication Module
