- Description: regulated SMPS - 1 or 2-phase - 100..240 V AC - 24 V - 5 A
- Product weight: 2.2 lb(US) (1 kg)
- Range of product: Phaseo
- IP degree of protection: IP20 conforming to EN/IEC 60529
- Standards: UL 508CSA C22.2 No 60950-1
- Width: 2.13 in (54 mm)
- Height: 4.72 in (120 mm)
- Depth: 4.72 in (120 mm)
- Operating altitude: 6561.68 ft. (2000 m)
- Connections - terminals: Screw type terminals input connection, connection capacity: 2 x 0.14...2 x 2.5 mm² AWG 26...AWG 14Screw type terminals output connection, connection capacity: 4 x 0.14...4 x 2.5 mm² AWG 26...AWG 14Screw type terminals input ground connection, connection capacity: 1 x 0.14...1 x 2.5 mm² AWG 26...AWG 14Screw type terminals output ground connection, connection capacity: 2 x 0.14...2 x 2.5 mm² AWG 26...AWG 14
- Mounting support: 35 x 15 mm symmetrical DIN rail35 x 7.5 mm symmetrical DIN rail75 x 7.5 mm symmetrical DIN rail
- Overvoltage category: Class I conforming to VDE 0106-1
- Relative humidity: 0...95 % without condensation or dripping water
- Input voltage: 100...240 V AC phase to phase, terminal(s): L1-L2100...240 V AC single phase, terminal(s): N-L1110...220 V DC
- Power supply type: Regulated switch mode
- Output voltage: 24 V DC
- rated power in W: 120 W
- Input protection type: Integrated fuse (not interchangeable)
- Power supply output current: 5:00 AM
- Input voltage limits: 100...250 V85...264 V
- Product certifications: RCMEACTUV 60950-1KC
- Product or component type: Power supply
- Network frequency: 47...63 Hz
- Inrush current: <= 30 A
- Environmental characteristic: EMC conforming to EN 50081-1EMC conforming to EN 50082-2EMC conforming to EN/IEC 61000-6-2Safety conforming to EN/IEC 60950Safety conforming to SELV
- Cos phi: 0.65
- Efficiency: 85%
- Ambient air temperature for storage: -13...158 °F (-25...70 °C)
- Output voltage limits: 100...120 % adjustable
- power dissipation in W: 21.2 W
- Current consumption: 1.2 A at 240 V1.9 A at 100 V
- Dielectric strength: Between input and groundBetween output and groundBetween input and outputBetween outputs
- Output protection type: Against overload, protection technology: 1.1 x InAgainst overvoltage, protection technology: tripping if U > 1.5 x UnAgainst short-circuits, protection technology: automatic resetAgainst undervoltage, protection technology: tripping if U < 0.8 x Un
- Line and load regulation: +/- 3 %
- Ambient air temperature for operation: 32...122 °F (0...50 °C) without122...140 °F (50...60 °C) with
- Holding time: >= 10 ms at 100 V>= 10 ms at 240 V
- Marking: CE
- Operating position: Vertical
- Output coupling: SeriesParallel
- Name of test: Conducted/radiated emissions conforming to EN 55011Conducted/radiated emissions conforming to EN 55022 Class BElectrostatic discharges conforming to EN/IEC 61000-4-2Emission conforming to EN 50081-1Induced electromagnetic field conforming to EN/IEC 61000-4-6Primary outage conforming to IEC 61000-4-11Radiated electromagnetic field conforming to EN/IEC 61000-4-3Rapid transient conforming to IEC 61000-4-4Surge conforming to EN/IEC 61000-4-5
- status LED: 1 LED green output voltage1 LED orange input voltage
Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on ABL8REM24050 . Santa Clara Systems carries 10,416 items from Telemecanique.
- Regulated Smps - 1 Or 2-Phase - 100..240 V Ac - 24 V - 5 A
