SJ-M201

Keyence - Compact Static Eliminator

Current response time:

17 Minutes 23 Seconds

Description: Compact Static Eliminator
Weight: Approx 300 g
Footnotes: *1 At installation distance 50 mm 1.97", air flow 60 Nl/min (ambient temperature 20 to 30C 68 to 86F, relative humidity 40 to 60%) *2 Values obtained at an installation distance of 50 mm 1.97" and air flow rate of 20 Nl/min ?ambient operating temperature +20 to +30C +68 to +86F, ambient operating humidity 40 to 60% RH? (without nozzle) *3 Inquire for derating of humidity/pressure in environments exceeding +35C 95F. Use clean or dry air at a temperature of -20C -4F or less. Min. air pressure varies by nozzle used.
Type: Controller Unit
Voltage application method: Pulse AC method
Applied voltage: 5.5 kV
Rated output voltage: 6 kV
Ion balance control method: I.C.C. method
Static elimination time: 0.5 sec max. *1
Ion balance: 15 V or less *2

Max. air pressure: 0.001 to 0.5 MPa *3
Control input - Static elimination stop input: Non-voltage input
Control output - Alarm output: NPN open c ollector 100 mA (40 V or less)
Control output - Ion level alarm output: NPN open c ollector 100 mA (40 V or less)
Control output - Condition alarm output: NPN open c ollector 100 mA (40 V or less)
Rating - Power voltage: 24 VDC 10%
Rating - Current consumption.: 450 mA max.
Environmental resistance - Operating temperature range: 0 to +40? 32F to 104F
Environmental resistance - Operating ambient humidity: 35 to 65% RH

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on SJ-M201 . Santa Clara Systems carries 2,107 items from Keyence.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
