PZ2-62P

Keyence - Photoelectric Sensor

Current response time:

By 5AM PT on Monday

Emergency?

Description: Photoelectric Sensor
Weight: Approx 50 g (including 2-m 6.6' connector cable)
Type: Retro-reflective model (for transparent object detection)
Response time: 1 ms max.
Light source: Red LED
Sensitivity adjustment: 1-turn trimmer (240)
Detection distance: 500 a (with R-2)
Detectable object: Transparent and opaque
Operation mode: LIGHT-ON/DARK-ON (switch-selectable)
Indicator lamp: Output indicator : Red LED,Stable operation indicator : Green LED
Control output: Maximum PNP open-collector output : 100 mA (40 V or less), residual voltage : 1 V or less

Protection circuit: Reversed polarity, overcurrent protection, surge absorber
Rating - Power voltage: 12 to 24 VDC 10%, ripple : 10% max., Class 2
Rating - Current consumption.: 35mA or less
Environmental resistance - Enclosure rating: IP67
Environmental resistance - Operating ambient luminance: Incandescent lamp : 5,000 lux or less, sunlight : 20,000 lux or less
Environmental resistance - Operating temperature range: -20 to +55C -4 to 131F (no freezing)
Environmental resistance - Operating ambient humidity: 35 to 85%RH (no condensation)
Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06" double amplitude for 2 hours in each of the X, Y, and Z directions
Environmental resistance - Shock resistance: 1,000 m/s2, 6 times in each of the X, Y, and Z directions
Case material: Glass-fiber reinforced plastic

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on PZ2-62P . Santa Clara Systems carries 2,103 items from Keyence.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
