FU-11

Keyence - Fiber Optic Sensor

Current response time:

By 5AM PT on Monday

Emergency?

Description: Fiber Optic Sensor
Weight: Approx 19 g
Footnotes: *1 The detecting distance is a value for white mat paper (the standard detection object) detections. *2 The minimum detectable object is the value when the detecting distance and sensitivity have been set to their optimal state.
Ambient temperature: -40 to +70C -40 to 158F
Fibre unit length: 2 m78.74" free-cut
Fibre unit diameter: 2.22
Minimum bend radius: R25 mm0.984"

Detection distance - MEGA/FINE - MEGA: 5 to 200 mm0.197" to 7.874"*1
Detection distance - MEGA/FINE - FINE: 5 to 140 mm0.197" to 5.512"*1
Detection distance - Other power modes - ULTRA: 5 to 200 mm0.197" to 7.874"*1
Detection distance - Other power modes - SUPER: 5 to 200 mm0.197" to 7.874"*1
Detection distance - Other power modes - TURBO: 5 to 160 mm0.197" to 6.299"*1
Detection distance - Other power modes - HSP: 5 to 110 mm0.197" to 4.331"*1
Minimum detectable object: Metal wire (parallel) with a diameter of 0.005 mm0.0002" *2

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on FU-11 . Santa Clara Systems carries 2,107 items from Keyence.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
