EZ-12M

Keyence - Proximity Switch

Current response time:

5 Minutes 24 Seconds

Description: Proximity Switch
Weight: Approx. 65 g
Type: Shielded
Accessories: Screw nut x 2, toothed washer x 1
Cable length: 2 m 6.6'
Shape: M12
Detecting distance: 2.5 mm 0.10" 10%
Detectable object: Ferrous metals (see Characteristics for nonferrous metals)
Standard target (iron, t=1mm 0.04"): 12 x 12 mm 0.47" x 0.47"
Hysteresis: 10% max. of detecting distance
Response frequency: 600 Hz

Operation mode: N.O./N.C.
Temperature characteristics: 10% max. of detecting distance at +23C 73.4F, within -25 to +70C -13 to 158F
Control output: NPN open collector 100 mA max. (40 V max.), Residual voltage: 1 V max.
Rating - Power voltage: 12 to 24 VDC 10%
Rating - Current consumption.: 13 mA max.
Environmental resistance - Enclosure rating: IP67
Environmental resistance - Operating temperature range: -25 to +80C -13 to 176F, No freezing
Environmental resistance - Operating ambient humidity: 35 to 95%, No condensation
Environmental resistance - Vibration: 10 to 55 Hz, 1.5 mm 0.06" double amplitude in X, Y, and Z directions, 2 hours
Environmental resistance - Shock resistance: 500 m/s2 1640.4' in X, Y, and Z directions, 3 times respectively
Case material: Nickel-plated brass
