IN320BF

Hubbell - Control

Current response time:

15 Minutes 15 Seconds

Description: Control
Specifications Description: Pin and Sleeve Replacement Interior, For, 3W 20A, IEC
UPC Number: 78358542002
Weight in LBs: 0.3
Flammability: UL94-5VA and V-0 classification.
Operating Temperatures: Maximum Continuous: 75 C; Minimum Continuous: -40 C w/o impact.
Current Interrupting: Certified for current interrupting at full rated current.
Terminal Identification: Terminals identified in accordance with North American and International conventions.
Ingress Protection: IP67 Suitability
Product Identification: Identification and ratings are a part of the external label and molded into the receptacle mount.
Impact Resistance: In accordance with UL746C
Max Working Voltage: 600V AC RMS
Replacement Part: Interiors
For Use With: IEC Devices
Interior Wiring Standard: 2 Pole, 3 Wire
Used In:: HBL316R4W, HBL316P4W, HBL316R6W, HBL316P6W, HBL320R6W, HBL320P6W, HBL320R7W, HBL320P7W

Hinge Spring: Stainless Steel (300 series)
Contact Carrier: High-Impact Thermoset
Retainer: High-Impact Thermoset
Terminal Screws: Stainless Steel (300 series)
Assembly Screws: Stainless Steel (300 series)
Gaskets: Neoprene
Ground/Phase Sleeve: Brass
Pin/Sleeve Spring: Stainless Steel (300 Series)
Certification: UL Listed, CSA Certified
Dielectric Withstand Voltage: Withstands 3,000V AC
Short Circuit Withstand: Suitable for use on a circuit capable of delivering not more than 10,000 RMS symmetrical amperes at the voltage rating of the receptacle.
Endurance: Mechanical: 10,000 cycles, Electrical: 6,000 cycles.
UV Resistance: All materials are UV Stabilized.
Certifications: UL Listed, CSA Certified.
Device Description: Replacement Interiors includes screws.
