Out of Stock

IG2810

Hubbell - Control

Current response time:

19 Minutes 56 Seconds

Description: Control
Specifications Description: 3P4W, 20A 125/250V, NEMA L14-20R, Orange
UPC Number: 78358587250
Weight in LBs: 0.3
Amperage: 30A
Poles and Wires: 4 Pole, 5 Wire
Mounting Screws: Steel, Zinc-Plated
Receptacle Blade Style: Twist-Lock
Receptacle Style: Single
Voltage/Power Rating: 3 Phase Wye 120/208V AC
Certifications: UL Listed File E2186
Listed To:: UL Standards 498 Receptacles

CSA Certified: To Specification C22.2 No. 42
Device Top: Nylon
Device Base: Nylon
Power Contact: .031" (.8) Brass
Contact Design: Tandem Modified Bypass
Mounting Strap: .050" (1.3) Steel-Zinc Coated
Clamping Plate: .031" (.8) Brass
Terminal Screws: #8-32 Brass
Grounding Screw: Steel (Green)
Auto Ground Clip: Stainless Steel
LED: Red

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on IG2810 . Santa Clara Systems carries 10,220 items from Hubbell.

We are in the process of adding data and downloadable material for this item. Please search similar items for more information related to this product.
