Out of Stock

HBL5362OWSA

Hubbell - Control

Current response time:

By 5AM PT on Friday

Emergency?

Description: Control
Specifications Description: 2P3W, 20A 125V AC, NEMA 5-20R, 240 joules/20KA per mode, Office White
UPC Number: 78358506029
Weight in LBs: 0.3
Amperage: 20A
Poles and Wires: 2 Pole, 3 Wire
Mounting Screws: Steel, Zinc-Plated
Receptacle Style: Duplex
Receptacle Grade: Standard
Voltage/Power Rating: 125V AC
Alarm: Audible and Visual
Certifications: UL Listed File E2186
Listed To:: UL Standards 498 Receptacles, Meets UL1449 TVSS
CSA Certified: To Specification C22.2 No. 42

ANSI/IEEE: C62.41 (IEEE 587)
Installation Categories: A (Ring Wave), "B" (Unidirectional Impulses)
Device Top: Nylon
Device Base: Nylon
Power Contact: .031" (.8) Brass
Contact Design: Tandem Modified Bypass
Mounting Strap: .050" (1.3) Steel-Zinc Coated
Clamping Plate: .031" (.8) Brass
Terminal Screws: #8-32 Brass
Grounding Screw: Steel (Green)
Auto Ground Clip: Stainless Steel
LED: Red
Alarm Muting Screw: Nylon
