F202-A-63-0.3-16-2-3HZ

ABB - F202 A-63/0.3 16-2/3Hz - Resid. Current Dev.

Current response time:

By 5AM PT on Monday

Emergency?

Description: F202 A-63/0.3 16-2/3Hz - Resid. Current Dev.
Product ID: 2CSF202196R3630
Extended Product Type: 2CSF202196R3630
Product Net Weight: 0.200 kg
Product Net Width: 0.035 m
Product Net Height: 0.085 m
Product Net Depth: 0.069 m
Standards: EN 61008
Number of Poles: 2
Rated Current (I<sub>n</sub>): 63 A
Power Loss: at Rated Operating Conditions per Pole 3.2 W
Type of Residual Current: A type
Rated Residual Current: 300 mA
EAN: 8012542733638
Minimum Order Quantity: 1 piece

Customs Tariff Number: 85363030
Package Level 1 Width: 0.041 m
Package Level 1 Height: 0.078 m
Package Level 1 Length: 0.096 m
Package Level 1 Gross Weight: 0.225 kg
Package Level 1 EAN: 8012542733638
Package Level 1 Units: 1 piece
Operating Characteristic: Instantaneous
Instructions and Manuals: 2CSF423001D6405
Data Sheet, Technical Information: 2CSC400002D0210
Declaration of Conformity - CE: 2CSC423001D2701
ETIM 4: EC000003 - Residual current circuit breaker (RCCB)
ETIM 5: EC000003 - Residual current circuit breaker (RCCB)
Object Classification Code: Q

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on F202-A-63-0.3-16-2-3HZ . Santa Clara Systems carries 36,972 items from ABB.

The Rccbs F200 Series Assures Protection To People And Installations Against Fault Current To Earth. A Large Offer For Standard Instantaneous And Selective Ac And A Types Is Completed With Some Configurations For Special Applications. This Version Can Work At Rated Frequency Of 16 2/3 Hz

The Rccbs F200 Series Assures Protection To People And Installations Against Fault Current To Earth. A Large Offer For Standard Instantaneous And Selective Ac And A Types Is Completed With Some Configurations For Special Applications. This Version Can Work At Rated Frequency Of 16 2/3 Hz
Common In Railways Applications.
