Out of Stock

DS201T-B10-A30

ABB - Breaker | DS201AT-B10/0,03

Current response time:

By 5AM PT on Thursday

Emergency?

Description: Breaker | DS201AT-B10/0,03
Product ID: 2CSR255148R1105
Extended Product Type: 2CSR255148R1105
Product Net Weight: 0.239 kg
Product Net Width: 0.035 m
Product Net Height: 0.085 m
Product Net Depth: 0.069 m
Standards: IEC 61009-1 IEC 61009-2-1 EN 61009-1 EN 61009-2-1
Number of Poles: 2
Rated Current (In): 10 A
Power Loss: 2.3 W
Tripping Characteristic: B
Type of Residual Current: A type
Number of Protected Poles: 1
Rated Residual Current: 30 mA
EAN: 8012542001935
Minimum Order Quantity: 1 piece

Customs Tariff Number: 85363010
Package Level 1 Width: 0.047 m
Package Level 1 Height: 0.078 m
Package Level 1 Length: 0.103 m
Package Level 1 Gross Weight: 0.274 kg
Package Level 1 EAN: 8012542001935
Package Level 1 Units: 1 piece
Rated Short-Circuit Capacity (Icn): (230 / 400 V AC) 6 kA
Position of Neutral Terminals: Right
RoHS Status: Following EU Directive 2011/65/EC
Instructions and Manuals: 9AKK106354A0766
Data Sheet, Technical Information: 2CSC422028L0201
Declaration of Conformity - CE: 9AKK106713A5588
RoHS Information: 2CSC422002K2701
ETIM 4: EC000905 - Earth leakage circuit breaker
ETIM 5: EC000905 - Earth leakage circuit breaker
Object Classification Code: Q

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on DS201T-B10-A30 . Santa Clara Systems carries 36,928 items from ABB.

Ds201 T 1p+n Rcbo Is A Device That In Two Modules Width Is Able To provide Complete Protection Against Overcurrent (Overload And Short Circuit) And Earth Fault And That Is Able To Meet The Demand Of A Device Suitable For Installation In Rolling Stock Equipment.
