Out of Stock

CT-AHE-1SVR550110R4100

ABB - CT-AHE Time relay, OFF-delay 1c/o, 0.3-30s, 110-130VAC

Current response time:

By 5AM PT on Friday

Emergency?

Description: CT-AHE Time relay, OFF-delay 1c/o, 0.3-30s, 110-130VAC
Product ID: 1SVR550110R4100
Extended Product Type: 1SVR550110R4100
Product Net Weight: 0.068 kg
Product Net Width: 22.5 mm
Product Net Height: 78 mm
Product Net Depth: 78.5 mm
Standards: IEC/EN 61812-1 UL 508 CAN/CSA C22.2 No.14
Terminal Type: Screw Terminals
Mounting on DIN Rail: TH35-7.5 (35 x 7.5 mm Mounting Rail) acc. to IEC 60715 TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
eClass: 7.0 27371790
Mounting Position: Any
GOST Certificate: GOST_8572616
GL Certificate: GL_94633-94HH
Rated Control Supply Voltage (U<sub>s</sub>): 110 ... 130 V AC
Output: 1 c/o (SPDT) contact
EAN: 4013614346262
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85364900
Package Level 1 Width: 84.2 mm
Package Level 1 Length: 24.6 mm

Package Level 1 Height: 83.1 mm
Package Level 1 Gross Weight: 0.081 kg
Package Level 1 Units: 1 piece
Time Range: 0.3-30 s
Timer Relay Type: OFF - Delay
RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
Instructions and Manuals: 1SVC550000M9000
CB Certificate: CB_DK-8575
CCC Certificate: CCC_2010010303393101
cUL Certificate: cUL508_E140448
Data Sheet, Technical Information: 2CDC111136D0201
Declaration of Conformity - CE: 1SVD981002-0000
EAC Certificate: EAC_RU_C-DE.ME77.B.02016
RMRS Certificate: RMRS_12.04010.250
RoHS Information: 1SAA981001-4404
UL Certificate: UL508_E140448
ETIM 4: EC001439 - Timer relay
ETIM 5: EC001439 - Timer relay
ETIM 6: EC001439 - Timer relay
UNSPSC: 39121500
Object Classification Code: K

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on CT-AHE-1SVR550110R4100 . Santa Clara Systems carries 36,937 items from ABB.

The Ct-Ahe Is A Single-Function Electronic Time Relay From The Ct-E Timer Range. It Provides An Off-Delay (Delay On Break) Function With A Time Range From 0.3 S To 30 S. This Time Relay Operates With A Rated Control Supply Voltage Of 110 - 130 V Ac And Has A 1 C/o (Spdt) Output Rated At 250 V / 4 A. A Control Input Works With Voltage-Related (Non-Floating) Triggering.
