CR-M024AC2L

ABB - CR-M024AC2L Pluggable interface relay 2c/o, A1-A2=24VAC, 250V/12A, LED

Current response time:

15 Minutes 10 Seconds

Description: CR-M024AC2L Pluggable interface relay 2c/o, A1-A2=24VAC, 250V/12A, LED
Product ID: 1SVR405611R0100
Extended Product Type: 1SVR405611R0100
Product Net Weight: 0.033 kg
Product Net Width: 21.2 mm
Product Net Height: 35.6 mm
Product Net Depth: 27.5 mm
Function: Pluggable miniature interface relay CR-M
eClass: 7.0 27371601
GOST Certificate: GOST_POCC_DE.AB76.D02256
Rated Control Supply Voltage (U<sub>s</sub>): 24 V AC
Sub-Function: Relay with built in LED
Output: 2 c/o (SPDT) contacts
EAN: 4013614497216
Minimum Order Quantity: 10 piece
Customs Tariff Number: 85364900
Package Level 1 Width: 114 mm
Package Level 1 Height: 61 mm
Package Level 1 Length: 50 mm
Package Level 1 Gross Weight: 0.35 kg
Package Level 1 EAN: 4013614373220

Package Level 1 Units: 10 piece
Output Signal: 250 V / 12 A
RoHS Status: Following EU Directive 2011/65/EC
Instructions and Manuals: 1SVC405600M9000
CCC Certificate: CCC_2014010303720193
CSA Certificate: CSA_2735700
cUR Certificate: cUR_E244330
Data Sheet, Technical Information: 2CDC117002D0204
Declaration of Conformity - CE: 1SVD982021-0000
EAC Certificate: EAC_RU_C-PL.ME77.B.01873
RMRS Certificate: RMRS_12.04008.250
RoHS Information: 1SAA981040-4404
UR Certificate: UR_E244330
VDE Certificate: VDE_40040327
E-nummer: 4005331
ETIM 4: EC001437 - Switching relay
ETIM 5: EC001437 - Switching relay
ETIM 6: EC001437 - Switching relay
UNSPSC: 39121500
Object Classification Code: K

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on CR-M024AC2L . Santa Clara Systems carries 36,972 items from ABB.

Holder And Marker Are Available As Accessories.

The Cr-M024ac2l Pluggable Interface Relay Is From The Cr-M (Miniature) Relay Range. This Relay Operates With A 24 V Ac Rated Control Supply Voltage And Has A 2 C/o (Spdt) Output With Contacts Rated At 250 V / 12 A. The Relay Has An Integrated Orange Test Button For Manual Actuation And Locking Of The Output Contacts And An Integrated Led. Standard Sockets
Logic Sockets
Pluggable Function Modules
