AF140-30-11B-33

ABB - AF140-30-11B-33 Contactor

Current response time:

By 5AM PT on Monday

Emergency?

Description: AF140-30-11B-33 Contactor
Product ID: 1SFL447002R3311
Extended Product Type: 1SFL447002R3311
Product Net Weight: 1.661 kg
Product Net Width: 90 mm
Product Net Height: 150 mm
Product Net Depth: 142.5 mm
Degree of Protection: acc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP20
Ambient Air Temperature: Close to Contactor Fitted with Thermal O/L Relay (0.85 ... 1.1 Uc) -25...+55 C Close to Contactor without Thermal O/L Relay (0.85 ... 1.1 Uc) -40...+70 C Close to Contactor for Storage -40+70 C
Rated Impulse Withstand Voltage (Uimp): 8 kV
Rated Insulation Voltage (Ui): acc. to UL/CSA 600 V acc. to IEC 60947-4-1 and VDE 0110 (Gr. C) 690 V
Terminal Type: Main Circuit: Bars
Rated Frequency (f): Main Circuit 60 Hz
Number of Auxiliary Contacts NO: 1
Number of Auxiliary Contacts NC: 1
Mechanical Durability: 5 million
Maximum Operating Altitude Permissible: 3000 m
Rated Control Circuit Voltage (Uc): 60 Hz 100250 V 50 Hz 100250 V DC Operation 100250 V
Maximum Mechanical Switching Frequency: 300 cycles per hour
Operate Time: Between Coil Energization and NO Contact Closing 2555 ms Between Coil De-energization and NO Contact Opening 3747 ms
Number of Main Contacts NO: 3
Number of Main Contacts NC: 0
Short-Circuit Protective Devices: gG Type Fuses 315 A

Coil Operating Limits: (acc. to IEC 60947-4-1) Uc (at 70 C) C
EAN: 7320500480878
Minimum Order Quantity: 1 piece
Customs Tariff Number: 85364900
Package Level 1 Width: 115 mm
Package Level 1 Length: 194 mm
Package Level 1 Height: 169 mm
Package Level 1 Gross Weight: 1.791 kg
Package Level 1 Units: 1 piece
Rated Operational Voltage: Main Circuit 690 V
Conventional Free-air Thermal Current (Ith): acc. to IEC 60947-4-1, Open Contactors q = 40 C 200 A
Rated Operational Current AC-3 (Ie): (415 V) 55 C 140 A (220 / 230 / 240 V) 55 C 140 A (690 V) 55 C 80 A (440 V) 55 C 140 A (380 / 400 V) 55 C 140 A (500 V) 55 C 80 A
Rated Operational Power AC-3 (Pe): (500 V) 55 kW (690 V) 75 kW (220 / 230 / 240 V) 37 kW (380 / 400 V) 75 kW (440 V) 90 kW (415 V) 75 kW
Rated Breaking Capacity AC-3 acc. to IEC 60947-4-1: 8 x Ie AC-3
Rated Making Capacity AC-3 acc. to IEC 60947-4-1: 10 x Ie AC-3
Rated Short-time Withstand Current (Icw): at 40 C Ambient Temp, in Free Air, from a Cold State 10 s 1168 A at 40 C Ambient Temp, in Free Air, from a Cold State 30 s 674 A at 40 C Ambient Temp, in Free Air, from a Cold State 15 min 200 A at 40 C Ambient Temp, in Free Air, from a Cold State 1 s 1460 A at 40 C Ambient Temp, in Free Air, from a Cold State 1 min 477 A
Maximum Electrical Switching Frequency: AC-3 300 cycles per hour AC-1 300 cycles per hour AC-2 / AC-4 150 cycles per hour
RoHS Status: Following EU Directive 2002/95/EC August 18, 2005 and amendment
Instructions and Manuals: 1SFC100003M0201
Data Sheet, Technical Information: 1SBC100192C02
RoHS Information: 1SFC101055D0202
UNSPSC: 39121529
Object Classification Code: Q

Santa Clara Systems specializes in hard-to-find parts. Choose from our overstock inventory and save on AF140-30-11B-33 . Santa Clara Systems carries 36,937 items from ABB.

Ac/dc

A 3-Phase Contactor Suitable For Various Applications Such As Motor Starting
Isolation
By-Pass And Distribution Application Up To Max 1000 V. Operated With Wide Control Voltage Range 100-250 V
